Weight grading machine

Model：FJ-10J-200G-A
Range：It is suitable for sorting small fish, such as dried sea cucumber, abalone, shrimp and other products.Can be devided into 12 grades. High precision, high efficiency.

Consultation

Contact

Weight grading machine can put products into hoppers, and check each product's weight accordint to specified category and level. Hoppers can be customized made according to product's feature, with better adaptability.It also helps to protect the sorted products from being damaged.The sorting level can be increased according to user needs, efficiently replacing manual sorting, and improving production efficiency and benefits.

Sorting model	FJ-10J-200G-A
Sorting categeries	5-21
Speed (per min) The speed is determined by the product itself and the filling weight	280-310
Sorting precision	0.1g
Sorting error	±0.3g-0.5g
Measurement (LWH)	（5-7 grade）3.411.6/（8-10 grade）4.211.6/（11-12 grade）4.511.6
Power supply	220V
Motor power	200W-400W
Weigh system	IP69
Material	SUS304
Measuring range	1g-100g
Protection grade	IP68/IP69K
